Code T8567351

Digital thermometer for laboratory mod. 735-1

The temperature measuring instrument mod. 735-1 allows you to solve almost all measurement functions.
Thanks to the wide range of optional probes, the instrument is in fact able to measure the temperature reliably in various sectors.
For example in a chemical laboratory to measure the temperature of aggressive substances or the temperature distribution in cold rooms, to calibrate stationary temperature probes or to measure the internal temperature in the food sector.
Regardless of the temperature to be measured (indoor, surface or air), in the wide range of accessories you will find the right temperature probe for your application to connect to the testo 735-1 to measure the temperature at six points simultaneously.
The temperature measuring instrument has an input for connecting high precision Pt100 probes and two inputs for K, T, J and S type thermocouple probes.

It is also designed for radio data transfer. With the optional radio module, the mod. 735-1 is able to receive the measurement values transmitted by three further radio probes.
The radio probes transmit the temperature values to the instrument up to 20 meters away as the crow flies.
Wireless measurement is a smart solution that avoids damage to cables or hindrances during use.
Thanks to the Pt100 technology, the 735-1 instrument allows to measure the temperature with extreme precision. The Pt100 immersion / penetration probe (optional), for example, boasts a system accuracy of up to 0.05 ° C with a resolution of 0.001 ° C. The temperature measuring instrument can then be used as a reference standard for calibrating stationary temperature probes.
The 735-1 instrument does not of course display only the momentary temperature. The min / max values and average values are also shown on its display. With two temperature probes connected, the temperature measuring instrument also calculates the differential temperature and displays it as a delta T value. It also emits an acoustic alarm whenever the upper or lower threshold is exceeded. The thresholds can be freely set.
The display illumination makes it easy to read the values even in the dark. The temperature measuring instrument mod. 735-1 is waterproof according to class IP 65, tested according to EN 13485, certified and HACCP compliant.
This instrument can be connected to an optional quick printer with which the temperature values or min / max values measured on site can be printed.
Or it is possible to take advantage of the practical cyclic printing function integrated in the 735-1 instrument which allows to print at freely selectable periodic intervals (for example once a minute) on the testo rapid printer not only single values, but also entire series of measurements.
For saving, documentation and archiving of measurement data we recommend the use of the model 735-2, which also has a memory for saving data and a PC software.

Equipment:
735-1 3-input temperature measuring instrument with acoustic alarm, test protocol and batteries.


ATTENTION: the instrument can only work in combination with a separately available probe.

Accessories on request:
- Fast printer with infrared wireless interface, 1 roll of thermal paper and 4 AA batteries
- Thermal printer paper (6 rolls), permanent ink
- Quick external charger for 1-4 AA-Ni-MH batteries
- Power supply, 5 VDC 500 mA, European connector, 100-250 VAC, 50-60 Hz
- Handle for connecting the measuring leads
- Silicone paste (14 g), T max = + 260 ° C
- Extension cable, 5 m, for thermocouple probe, type K
- Radio module for measuring instrument, 869.85 MHz, approved for the following countries: DE, FR, UK, BE, NL, ES, IT, SE, AT, DK, FI, HU, CZ, PL, GR, CH , PT, SI, MT, CY, SK, LU, EE, LT, IE, LV, NO

Casing

ABS / TPE / metal

Protection class

IP65

Standards

EN 13485

Warranty

2 years

Battery type

Alkaline-manganese, mignon, type AA

Storage temperature

-30 to +70 ° C

Weight

428 g

Dimensions

220 x 74 x 46 mm

Working temperature

-20 to +50 ° C

Accessories

Code T8614235
PT 100 probe for high precision immersion-penetration
Code T8691273
PT 100 probe for waterproof immersion-penetration
Code T8691773
PT 100 per air probe
