Porcelain perforated plates for dryer

Perforated ceramic discs, with ventilation holes and central hole.

Compliant with DIN 12 911



LABORATORY PORCELAIN

Technical features

It is characterized by its high quality.

Chemical and heat resistance complies with the requirements of EN 1183 and ISO 1775.

The manufacturing material is located within the C110 group according to the EN 60672-3 standards.

Tolerances on product dimensions comply with DIN 40680 standards,

Unglazed products can be used at temperatures up to 1350 ° C / 2462 ° F and enamelled products at temperatures up to 1,000 ° C / 1,832 ° F

The products have a high resistance to acids and bases.

Other properties:

density (g / cm3) = 2.4,

resistance to flexion / expansion of unglazed products (70MPa),

thermal conductivity (w. m-1.K-1) = 1.3

Code Description
1141101 Porcelain perforated plate diam. 90
1141102 Porcelain perforated plate diam. 140
1141103 Porcelain perforated plate diam. 190
1141104 Porcelain perforated plate diam. 240
1141105 Porcelain perforated plate diam. 290
